1. Topics of interest were defined following a risk based approach. 2. Study priorities were set based on knowledge gaps in current practices, but they were conditioned by pragmatic limitations. 3. Focus topics : failure modes, detection and monitoring and repairs. 4. Serious failures can occur in sections with large burrows (e.g. fox and beaver holes), but also in sections with mole burrows. Research in progress. 5. Detection and monitoring techniques were developed and tested in the living lab, but results are site specific. Further testing is needed for benchmarking. 6. A low cost repair technique was developed and evaluated.
DOCUMENT
This report bundles the annexes for the data report of the overflow tests executed on the Dutch part of the Hedwige-Propserpolder levees. Overflow tests on levees are designed to test the strength of levees and levee covers under the load of a continuously overflowing discharge of water. For this purpose, Flanders Hydraulics Research have designed and built an Overflow Generator (Vercruysse et al., 2022) within the framework of the Polder2C’s project. This device allows to generate a controlled and homogenous discharge of water over the levee crest. Within the Polder2C’s project, 25 overflow tests on Belgian and Dutch levee stretches have been executed in 3 episodes from 30/10/20 to 28/11/20, 17/02/21 to 31/03/21 and 16/11/21 to 20/12/21. Different test goals have been addressed, to understand the normal performance of a levee cover, and the influence of different anomalies and/or deviations from the ‘standard’ levee.
DOCUMENT
Report on testing of water overflow on Dutch levees. On the Dutch part of the levee in Hedwige-Prosperpolder, 11 overflow tests have been conducted. Overflow tests on levees are designed to test the strength of levees and levee covers under the load of a continuously overflowing discharge of water. For this purpose, Flanders Hydraulics Research have designed and built an Overflow Generator (Vercruysse et al., 2022) within the framework of the Polder2C’s project. This device allows to generate a controlled and homogenous discharge of water over the levee crest. Within the Polder2C’s project, 27 overflow tests on 11 Belgian and 11 Dutch levee stretches have been executed in 3 episodes from 30/10/20 to 28/11/20, 17/02/21 to 31/03/21 and 16/11/21 to 20/12/21. Different test goals have been addressed, to understand the normal performance of a levee cover, and the influence of different anomalies and/or deviations from the ‘standard’ levee.
DOCUMENT
Report on testing of water overflow on Belgian levees. On the Belgian part of the levee at the Prosperpolder, 14 overflow tests have been conducted on 12 sections. Continuous overflow tests on levees are designed and executed to test the strength of levees and levee covers under the load of a continuously overflowing discharge of water. For this purpose, Flanders Hydraulics has designed and built an Overflow Generator (Vercruysse et al., 2022) within the framework of the Interreg Polder2C’s project. This device allows to generate a controlled and homogenous discharge of water flowing over the levee crest and slopes. Within the Polder2C’s project, 27 overflow tests on Belgian and Dutch levee stretches have been executed in 3 episodes from 30/10/20 to 28/11/20, 17/02/21 to 31/03/21 and 16/11/21 to 20/12/21. Different test goals have been addressed, to understand the normal performance of a levee cover, and the influence of different anomalies and/or deviations from the ‘standard’ levee.
DOCUMENT
This report bundles the annexes for the data report of the overflow tests executed on the Belgian part of the Hedwige-Propserpolder levees. Overflow tests on levees are designed to test the strength of levees and levee covers under the load of a continuously overflowing discharge of water. For this purpose, Flanders Hydraulics Research have designed and built an Overflow Generator (Vercruysse et al., 2022) within the framework of the Polder2C’s project. This device allows to generate a controlled and homogenous discharge of water over the levee crest. Within the Polder2C’s project, 27 overflow tests on Belgian and Dutch levee stretches have been executed in 3 episodes from 30/10/20 to 28/11/20, 17/02/21 to 31/03/21 and 16/11/21 to 20/12/21. Different test goals have been addressed, to understand the normal performance of a levee cover, and the influence of different anomalies and/or deviations from the ‘standard’ levee.
DOCUMENT
Animal burrows create discontinuities on the body of earthen levees that under certain circumstances can threaten their structural integrity through hydraulic alteration and surface erosion. Although it is a virtually established fact that discontinuities can undermine the structural integrity of levees, there are limited studies that clarify when animal activity can be considered dangerous and which are the most effective approaches for dealing with it. Interaction with levee management agencies in the network of Polder2C’s has shown that there is much tacit knowledge on the topic among levee guards in the Netherlands, Belgium, France and the UK, which has only been marginally reported so far. It is also of interest that the Dutch Government approved the inclusion of measures against harmful animal activity in flood defences more than a decade ago (Tweede Kamer 2010), but to this end, an integrated national management framework is still pending. This highlights the fact that formal knowledge on the topic is limited and fragmented. In order to enable the development of a rational framework for dealing with animal activity on levees, a coordinated effort is required for the review and reporting of existing knowledge, identification of knowledge gaps and development of approaches to determine the level of risk incurred by various types of animal activities on levees and the effectiveness of reduction actions. This report presents activities that took place within Polder2C’s and could support the development of such a rational framework. After the first winter of experimentation in the Living Lab Hedwige-Prosperpolder, evidence was produced about possible adverse impact of animal- and vegetation-induced discontinuities on levees (Holscher & Zomer, 2021; Koelewijn et al. 2021). Overflow experiments at locations of anomalies caused by grazing sheep, trees and fox holes led to severe erosion of the structure within a considerably short time (see also Figure 1.2a). In June 2021 a mole burrow system was detected in a levee section that had been damaged during overflow experiments and where an emergency repair application with rock bags had been subsequently applied. In order to explore the geometry and extent of the system, the mole tunnels were grouted with fast drying concrete. Upon excavation of the concrete an extensive burrow system was revealed with exit points close to the toe and close to the crest of the section (see also b). In preparation of the second winter of experimentation, a cross-work package team was created to identify knowledge gaps in the management of animal burrows on levees and suggest research activities that could potentially fill in identified gaps. This led to a longlist of possible activities, a number of which were eventually executed in the period September 2021 till February 2022. The final selection of activities was limited by the contractor’s work and other large-scale experiments and exercises. Priority was given to activities that had no conflicts with the abovementioned operations and for which there was available equipment and manpower within the involved organizations. This report presents the work that was performed within Polder2C’s on the management of harmful animal activity on levees in a chronological order. It starts with a description of observations in the first year of the project, and a subsequent study that led to the development of a knowledge agenda in the period February till June 2021. It continues with a description of activities that took place in a more coordinated manner in the second year of the project and it ends with a summary of key findings.
DOCUMENT
Engineers design levees without taking into account animal activity. But in reality: *Levees attract burrowing animals *Many of them are protected (e.g. beavers) *It is not always easy to detect burrows and remove them Topics of interest are: 1. Eco engineering approaches for deterrence of animals How can we make animals go elsewhere? 2. Detection and measurement techniques How can we find burrows on a levee and measure their geometry? 3. Failure paths How do levees fail when they have burrows? 4. Effectiveness of countermeasures How can we repair levee damages made by burrowing animal?s
DOCUMENT
Seminar at Lille University, 2 February 2023 The main objectives of the living lab Hedwige-Prosperpolder are: - Build capacity to cope with the adverse effects of climate change - Advance and share knowledge on the design and maintenance of levees - Advance and share knowledge and experiences in flood emergency response - Develop a sound knowledge infrastructure that facilitates knowledge transfer across countries and generations - Disseminate results to various audiences
DOCUMENT
Poster. Polder2C’s is an Interreg-funded project that aims at flood resilience building through fieldwork in the Living Lab Hedwige-Prosperpolder (LLHPP). LLHPP consisted of a 3 Km-long levee where various large-scale surveys, superstorm simulations and emergency response exercises took place in the winters period 2020-21 and 2021-22. The levee was recently removed to facilitate the expansion of an adjacent intertidal area.
DOCUMENT
Infosheet. Within the context of animal burrows surveys that took place in the test season 2021-2022 in the living lab Hedwige-Prosperpolder, an experimental setup with smoke bombs was developed to verify whether detected burrows by small rodents are interconnected in the subsurface. By injecting colored smoke in one of the detected burrows the team could observe if the smoke would exit the ground from other burrows in the proximity gaining insight into the extent of subsurface connections of burrows. The detection of several exit points is a sign that there is a system of tunnels in the levee that leads to a den. This is most likely a weak spot on the levee that requires attention by the levee managers. The test was repeated 5 times using different variants in its assembly and also testing burrows by larger animals. This helped to gradually improve the setup and make it more practical for use by levee inspectors.
